Tyke 10 (27.5'')

Product categories

Tyke 10 (27.5'')

Retail Price

1,610.00

This Bike is Available in other Colours - Please Request more information

FRAME Equipped with thru axles, lightweight and tough SXC aluminium alloy frame with trail-optimised geometry and ultra-sensitive four-barsuspensions system for full in-trail control and comfort. DRIVETRAIN 2×10 Shimano Deore/SLX drivetrain ensures swift shifting and wide gear range to fit every off-road condition. BRAKES Shimano hydraulic disc brake system with 160 mm rotors gives the rider the confidence to control the speed in every situation with ease and precision. FORK Air-sprung SR Suntour XCR with Remote Speed Lockout and 15Q-Loc thru axle provides full control and confidence even on the toughest trails and great uphill performance on the steep parts.

Specifications

  • FRAME: KELLYS SXC 27.5 / Four-bar link, 120mm rear travel, tapered HT, internal routing, 12x142mm thru axle
  • FRAME SIZE: S / M / L
  • FORK: SR SUNTOUR XCR LOR Air (27.5), 120mm, air / Speed Lockout / 15Q-Loc thru axle
  • REAR SHOCK: ROCK SHOX Monarch R, Solo Air / Rebound (184x44mm)
  • HEAD PARTS: KLS Master 1.5 integrated
  • CRANKSET: KLS Advanced integrated (36×26) – length 170mm (S), 175mm (M – L)
  • SHIFTERS: SHIMANO Deore (18) SL-M6000 Rapidfire Plus
  • F/DERAILLEUR: SHIMANO Deore M616-D (direct mount)
  • R/DERAILLEUR: SHIMANO SLX M670 (direct mount)
  • SPEED: 20
  • CASSETTE SPROCKET: SHIMANO CS-HG50-10 (11-36)
  • CHAIN: KMC X10EL (110 links)
  • BRAKES: SHIMANO M365 Hydraulic Disc
  • BRAKE ROTORS: SHIMANO 160mm front / 160mm rear
  • BRAKE LEVERS: SHIMANO BL-M365
  • HUBS: NOVATEC Disc (15x100mm / 12x142mm / 32 holes)
  • THRU AXLE: SR SUNTOUR Q-Loc 15x100mm front / NOVATEC 12x142mm rear
  • RIMS: KLS Cartel Disc 584×21 (32 holes)
  • SPOKES: stainless steel black
  • TIRES: SCHWALBE Rapid Rob 57-584 (27.5×2.25)
  • STEM: KLS Active – diam 28.6mm / bar bore 31.8mm / 7° / length 70mm (S), 80mm (M), 90mm (L)
  • HANDLEBAR: KLS Active RiseBar – diam 31.8mm / width 680mm (S), 700mm (M), 720mm (L)
  • GRIPS: KLS Advancer
  • SEAT POST: KLS Active – diam 31.6mm / length 350mm (S), 400mm (M – L)
  • SADDLE: KLS Fluo
  • PEDALS: KLS Master – alloy

Frame Size

Geometry
