Reyon 10

Product categories

Reyon 10

Retail Price

1,660.00

This Bike is Available in other Colours - Please Request more information

Out of stock

FRAME

Virtual pivot rear end with Ratio Trail Control Link provides top suspension performance for great pedalling efficiency along with the grip and control even under heavy terrain conditions.

DRIVETRAIN

2×10 Shimano Deore/SLX drivetrain ensures swift shifting and wide gear range to fit every off-road condition.

FORK

Air-sprung SR Suntour XCR with Remote Speed Lockout and QR axle provides full control and confidence even on the toughest trails and great uphill performance on the steep parts.

BRAKES

Shimano hydraulic disc brake system with 160mm rotors gives the rider the confidence to control the speed in every situation with ease and precision.





Specifications

  • FRAME: KELLYS SXC Marathon 29 SWT 6061 (12x148mm Boost thru axle) / Ratio Trail Control Link, 100mm rear travel
  • FRAME SIZE: S (17″) / M (19″) / L (21″)
  • FORK: SR SUNTOUR XCR LO-R Air (29), 100mm, air / Speed Lockout / 15Q-Loc thru axle
  • REAR SHOCK: ROCK SHOX Monarch R, Solo Air / Rebound (size 165x38mm)
  • HEAD PARTS: KLS Master 1.5 integrated
  • B.B.PARTS: FSA PressFit
  • CRANKSET: FSA Comet Modular Megaexo (36×24) integrated – length 170mm (S), 175mm (M – L)
  • SHIFTERS: SHIMANO Deore SL-M610 Rapidfire Plus
  • F/DERAILLEUR: SHIMANO Deore M617-D (direct mount)
  • R/DERAILLEUR: SHIMANO SLX M670 (direct mount)
  • SPEED: 20
  • CASSETTE SPROCKET: SHIMANO CS-HG50-10 (11-36)
  • CHAIN: KMC X10EL (112 links)
  • BRAKES: SHIMANO M365 Hydraulic Disc
  • BRAKE ROTORS: 160mm front / 160mm rear
  • BRAKE LEVERS: SHIMANO BL-M365
  • HUBS: NOVATEC Disc (15x100mm / 12x142mm / 32 holes)
  • THRU AXLE: SR SUNTOUR Q-Loc 15x100mm front / Rock Shox Maxle Lite 12x142mm rear
  • RIMS: KLS Cartel Disc 622×21 (32 holes)
  • SPOKES: stainless steel black
  • TIRES: SCHWALBE Rapid Rob 57-622 (29×2.25)
  • STEM: KLS Active – diam 28.6mm / bar bore 31.8mm / 7° / length 90mm (S), 100mm (M), 110mm (L)
  • HANDLEBAR: KLS Master FlatBar – diam 31.8mm / width 680mm (S), 700mm (M), 720mm (L)
  • GRIPS: KLS Advancer 2Density
  • SEAT POST: KLS Expert – diam 30.9mm / length 350mm (S), 400mm (M – L)
  • SADDLE: KLS Avenger
  • PEDALS: KLS Master – alloy

Geometry
